CONNECTIVITY ON THE V3X BOARDS COD A AND COD B
MODULES FOR 3D AND 1080P IN SINGLE-LINK 3G-SDI
Connector Assignments
Connec-tor 3D/1080p Mode Connector label
J1 N/A CHAR SD
J2 SDI program output 2D
(SD, down-converted)
Not wired to the
backplane.
Used for onboard
multiviewer input
J3 SDI program output 2D
(HD/SD)
OUT B
J4 SDI monitoring output for left eye (3D)
or link 1 (1080p)
(HD/SD)
CHAR OUT SD/HD
J5 Not installed IN B
J6 3G-SDI program output for left & right
eyes (3D) or link 1 & 2 (1080p)
(3G)
OUT
J7 3G-SDI program output for left & right
eyes (3D) or link 1 & 2 (1080p)
(3G, identical to J6)
OUT
J8 3G-SDI input left & right eyes (3D) or
link 1 & 2 (1080p)
(3G)
IN
J9
Alternate 3G-SDI input
(3G, for hardware loop)
Not wired to the
backplane.
Used for loop in.
Note
The loops of the input signal are not genlocked.
