EVS XTnano User Manual

V3X COD Modules LEDs
The following table lists the LEDs available on then V3X COD modules (from left to right):
LED Color Status Function
CPU Green Blinking Indicates CPU activity.
On There is a problem with the module processor.
PLAY Green On The module is set in play mode by the software.
Off The module is set in record mode.
PVID Green On A valid video signal has been detected on the J8
connector (SD/HD SDI input), whether the module is in
play or record mode.
TF
(transfer)
Green Blinking Data transfers occur between the module and the H3X
board.
M1 — — Not used.
M2
M3
M4
6.2.2. CODConnectivity in SD and HD
This section describes the connector assignments and layout for the video standards SD
525i, SD 625i, HD 1080i and HD 720p.
The specific connectivity for HD 3D Dual Link is described in the following sections.
38 6. Boards Description
EVS Broadcast Equipment S.A. - January 2013 Issue 11.01.C
