EVS XTnano User Manual

5.2. Rear Panel Description
5.2.1. Rear Panel Configurations
The XTnano server is available in one configuration but various rear panel variants:
• 4U rack with 4 channels and various audio connectors.
The different connectors positions and types for each of these variants are described in
the following topics.
5.2.2. 4U Rear Panel Layout
Rear Panel Areas
The following drawing represents an example of a 4U rear panel available on an XTnano
server.
The various areas of the rear panel are highlighted in the drawing and their respective
variants are listed in the following table along with a short description of the related
connectors.
XTnano Server- Version 11.01- Hardware Technical Reference Manual
5. Hardware Installation and Cabling 17
