Controls and Communications

This rear panel part presents some or all of the following connectors according to your

configuration:

• The Ref Video connectors allow the server to receive or send back the analog

genlock reference signal.

• The Multiviewer connectors allow a monitor to be connected directly to the server,

and to display PGM and REC channels as configured in the Multicam Configuration

window, in the Monitoring tab, Multiviewer page. See the Multicam Configuration

manual for a description of the configuration parameters.

• The Loop IN connector allows the loop of PGM1 on REC1 to be able to use the loop

feature.

• The Timecode connectors allow the server to receive or send back the LTC timecode

reference signal.

• The Gigabit Ethernet connectors allow the interconnection of servers, other EVS,

and/or third-party systems into a Gigabit Ethernet network.

• The Multiviewer connector provides an analog Multiviewer output on a DA-15

connectors, that can be configured in CVBS, RGB HD or YUV HD.

• The GPI connector allows GPI (General Purpose Interface) devices to send or

receive electric pulses that will trigger commands on the server or to be connected

with third-party devices.

• The Console connector allows a monitor and a keyboard to be connected to the

server.

Controls and Communications

This rear panel part presents some or all of the following connectors according to your

configuration:

• The PC LAN connector is a XLR connector that enables the connection to the PC

LAN network.

• The Audio Monitoring Outputs connectors are AES XLR connectors that allow

audio output connections for monitoring purposes.

Power Supplies

The server power supply is made of two hot-swappable units. Both of these units are

connected to allow automatic power switching to the second power supply should the first

one fail.

20 5. Hardware Installation and Cabling

EVS Broadcast Equipment S.A. - January 2013 Issue 11.01.C

EVS XTnano User Manual
