EVS XTnano User Manual

LEDs Function
The available LEDs on the XNet2CTL controller module are, from left to right:
LED Color Status Function
LED 1 Green On Ok.
Red On An error occurred while booting the H3X board.
LED 2 to
LED 8
— — For EVS internal use only.
FRAMER Green On Not used.
NET Green On Not used.
DSP Green Blinking Indicates DSP activity (audio processing).
The available LEDs on the GBE Gigabit module module are, from left to right:
LED Color Status Function
CPU1
CPU2
Green Blinking These LEDs blink alternately every 250 milliseconds to
indicate that the processor is running.
Other
LEDs
— — For EVS internal use only.
Gigabit Connectors
The two board Gigabit connectors are connected to the two backplane Gigabit ports.
The Gigabit connectors must be on a network that supports Jumbo Frames of (at least)
9014 bytes Ethernet frames. One of the tested switch belongs to the Cisco 3750 G family,
for example the WS-C3750G-24T-S.
You can set up the GigE IP addresses in the Multicam Configuration window, in the
Network tab, Gigabit Ethernet section.See the Configuration manual for more information.
46 6. Boards Description
EVS Broadcast Equipment S.A. - January 2013 Issue 11.01.C
