EWM Pico 162 - Technical Data: Pico 162 (230 V)

T
echnical data
Pico 162 (230 V)
34
099-002040-EW501
28.04.2014
8 Technical data
NOTE
Performance specifications and guarantee only in connection with original spare and
replacement parts!
8.1 Pico 162 (230 V)
MMA
TIG
Welding current
10 A–150 A 10 A–160 A
Welding voltage
20.4 V–26.0 V 10.4 V–16.4 V
Duty cycle 25 °C
150 A (50%)
120 A (100%)
160 A (45%)
120 A (100%)
Duty cycle 40 °C
150 A/35%
120 A/60%
100 A/100%
160 A/30%
130 A/60%
100 A/100%
Load alternation
10 min. (60% DC
∧
6 min. welding, 4 min. pause)
Open circuit voltage
105 V
33 V (Pico 162 VRD)
Mains voltage
1 x 230 V
Mains voltage tolerance
-40% to +15% (Pico 162; Pico 162 VRD)
-20% to +15% (Pico 162 MV)
Frequency
50/60 Hz
Mains fuse (safety fuse, slow-blow)
20 A 16 A
Mains connection lead
H07RN-F3G2.5
Max. connected load
6.4 kVA 4.6 kVA
Recommended generator rating
8.6 kVA
cos
ϕ
with Imax
0.99
Insulation class/protection classification
H/IP 23
Ambient temperature
-25 °C to +40 °C
Machine cooling/torch cooling
Fan/gas
Workpiece lead
16 mm
2
Dimensions L/W/H
430 mm x 115 mm x 225 mm
Weight
6.9 kg (Pico 162; Pico 162 VRD)
7.1 kg (Pico 162 MV)
EMC class
A
Constructed to standard
IEC 60974-1, -10 / /
AS 1674.2-2003, Category C (VRD)
