209173 RCD-2
Index A
81
8.2.3 Power distributor
- The electronic charge dividers isolate the battery banks from each other and allow the charge to be directed automatically to the battery with the lowest charge. They provide
the advantage of preventing a drop in voltage.
- The charge divider is electronic. It is designed to distribute the charging current with a low voltage drop between the battery banks (engine and service batteries). It prevents
the current from circulating from one battery to another. When the voltage of the charger or alternator is available, the charge divider indicator lights up green.
8.2.4 Connection of the battery bank
If one of the engine batteries is low on power, use the battery link function by actuating the linking system.
Location: Port and starboard engine compartment
Location: Port engine compartment
Electrical system
