Operation
ProductOverview
Figure3
1.Grassbag
5.Dischargedoor
2.Handle6.Rearwheelheight
adjustment
3.DriveBail
(Self-PropelledUnits
Only)
7.Frontwheelheight
adjuster
4.BladeControlBail
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Controls
BladeControlBail
LocatedontheupperhandleasshowninFigure4.
Whenthebladecontrolbailisdepressed,thesystem
sensesthattheoperatorisinthenormaloperator's
position.
•ForUnitswithaBladeBrakeClutch:When
thebladecontrolbailisreleased,thesystem
sensesthattheoperatorhasmovedfromthe
normaloperatingpositionandwillstoptheblade.
•ForUnitswithoutaBladeBrakeClutch:
Whenthebladecontrolbailisreleased,thesystem
sensesthattheoperatorhasmovedfromthe
normaloperatingpositionandwillkilltheengine.
Figure4
BladeBrakeUnitShown
1.Bladecontrollocklever(BladeBrakeUnitsOnly)
2.Bladecontrolbail
3.Handle
4.Drivebail(Self-PropelledUnitsOnly)
Self-PropelDriveBail(Self-Propelled
UnitsOnly)
LocatedontheupperhandleasshowninFigure4.
Whentheself-propeldrivebailissqueezedagainst
thehandle,theunitgroundspeedwillchangebased
13
