Operation
WARNING
Adjustingthecuttingheightleverscouldbring
yourhandsintocontactwithamovingblade.A
movingbladecancauseseriousinjury.
•Stoptheengineandwaitforallmovementto
stopbeforeadjustingthecuttingheight.
•DoNotputyourngersunderthehousing
whenadjustingthecuttingheight.
•RearWheelAdjustment:
1.Pullthewheelheightadjustmentrodupward
toreleasethepinfromthenotchinthe
adjustmentbracket(Figure13).
Figure13
1.Pullupward4.Pin
2.Wheelheightadjustment
rod
5.Rotatetodesiredsetting
3.Adjustmentbracket6.Indicator
2.Applydownwardpressureorliftthehousing
torotatetheheightadjustmentbracket.Use
theindicatortodeterminethedesiredsetting.
3.Releasethewheelheightadjustmentrodtoset
thepinsecurelyinthedesirednotch.
•FrontWheelAdjustment
1.Pullupontheheightadjusterandpullthe
frontwheelshaftassemblyoutwardasshown
inFigure14.
Figure14
1.Frontwheelshaft
assembly
4.Frontquadrantblockcut
heights
2.Pullup5.Pulloutward
3.Heightadjuster
6.Shaftgroove
2.Insertthefrontwheelshaftassemblyintothe
desiredcutheightsettinginthefrontquadrant
block.Lowertheheightadjusterintothe
grooveonthefrontwheelshaft.Pulland
pushthewheelshaftassemblytomakesureit
haslockedintoplace.
UsingtheGrassBag
•InstallingtheGrassBag
1.Stoptheengineandwaitforallmovingparts
tostop.
2.Openthereardoor.
3.Graspthehandleonthebagandsettherear
ofthebagframeontothedoorhingebracket
(Figure15).
19
