Operation
Thefuelshut-offvalveisusedtoshutoffthefuel
whenthemachinewillnotbeusedforafewdays,
duringtransporttoandfromthejobsite,andwhen
parkedinsideabuilding.
Alignvalvehandlewiththefuellinetoopen.Rotate
90°toclose.
FuelGauge
(ForallLZEModelsandallLZS/LZX
KawasakiModelsExceptRED
EquippedModels)
Locatedontherightconsoleinthemessagedisplay.
Thefuellevelisshownonabardisplay.Theindicator
lightappearswhenthefuellevelislow(approximately
onegallonremaininginthetank).
FuelGauge
(ForLZSKohlerEFIModels)
Locatedontherightconsoleinthemessagedisplay.
TheLEDwillasharedlightandthefuellevel
symbolonthedefaultscreenwillash.
FuelGauge(REDEquippedModels)
LocatedontheinformationscreenoftheRED
EquippedLDUoftheRHconsole.
Thefuellevelisshownonabardisplay.Theindicator
lightappearswhenthefuellevelislow(approximately
onegallonremaininginthetank).
DriveWheelReleaseValves
WARNING
Handsmaybecomeentangledintherotating
drivecomponentsbelowtheenginedeck,which
couldresultinseriousinjuryordeath.
Stopengine,removekey,allowallthemoving
partstostopbeforeaccessingthedrivewheel
releasevalves.
WARNING
Theengineandhydraulicdriveunitscanbecome
veryhot.Touchingahotengineorhydraulic
driveunitscancausesevereburns.
Allowtheengineandhydraulicdriveunitsto
coolcompletelybeforeaccessingthedrivewheel
releasevalves.
Locatedonthebackoftheunitizedhydraulicdrive
units,belowtheenginedeck.
Duringnormaloperatingconditions,thedrivewheel
releasevalvesarepositionedhorizontally.Ifthe
machinehastobepushedbyhand,thevalvesmust
beinthe“released”position(seeFigure13).
g008609
Figure13
CoolingFanCongurationShown
1.Handlein“released”position
2.Handlein“operating”position
Toreleasethedrivesystem(seeitem1inFigure13),
rotatethehandle1/4turntotheverticalposition
untilithitsagainstthestop.
Toresetthedrivesystem(seeitem2inFigure13),
rotatethehandle1/4turntothehorizontalposition
untilithitsagainstthestop.
Note:Thehandlemustbehorizontalandagainst
thestopforoperation.
DoNottowmachine.
PTOEngagementSwitch(AllModels
ExceptLZSandLZXEFIModels)
Locatedonrightconsole(seeFigure6andFigure7).
Switchmustbepulledout(up)toengagetheblades.
Switchispushedintodisengagetheblades.
