Exmark LAZER Z Parts Manual

9
FRONT FRAME GROUP
Exmark red touch up spray paint - P/N 850337
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 632518 Frame wldmt, front 52”........... 1 32
633064 Spring, deck support (52”
& 60”) 2
632513 Frame wldmt, front 60”........... 1 643015 Spring, deck support (72”)...... 2
642046 Frame wldmt, front 72”........... 1
33
804755 Jam nut, 5/8-11....................... 4
2
811006 Zerk, 1/4-28 straight................ 5
34
543513 Cap, grease ............................ 2
3
633556 Floorpan ................................. 1
35
543509 Bearing cone, tapered roller ... 4
4
633553 Pad, anti skid........................... 3 543508 Bearing cup, tapered roller ..... 4
5
634312 Lever w/grip............................ 1
36
543511 Seal, grease............................ 2
632324 Lever wldmt, lift ...................... 1
37
632511 Caster wldmt (52” Koh)........... 2
6
633295 Grip, lift lever ........................... 1 642111 Caster wldmt
(52” Kaw, 60” & 72”)
2
7
632219 Arm wldmt, deck lift................. 1
38
804266 Nut, 3/4-10 nylock................... 2
8
633325 Spring, compression ............... 1
39
633508 Washer, spring disk...... .......... 6
9
805259 Washer, 3/8 SAE flat............... 1
40
800339 Screw, 1/2-13x7 ½ (52” Koh).... 2
10
804257 Nut, nylock 3/8-16 ................... 5 800335 Screw
,
1/2-13x9
(52” Kaw
,
60” & 72”)
2
11
808505 E-ring....................................... 5
41
811010 Plug ........................................ 2
12
633068 Arm, deck lift ........................... 2
42
634662 Caster wheel assy (52” Koh)... 2
13
806761 Cotter pin, 1/8 x 3/4................. 2 644251 Caster wheel assy
14
808284 Clevis pin, 3/8 x 1.................... 2 (52” Kaw, 60” & 72”)............. 2
15
633889 Plate, deck lift.......................... 1
43
804269 Nut, 1/2-13 nylock.(light thin).. 2
16
632899 Plate wldmt, deck lift................ 1
44
633579 Spacer, front caster (52” Koh) 2
17
633082 Bushing, lift lever..................... 1 633959 Spacer, front caster
18
633080 Bushing, lift lever..................... 1 (52” Kaw, 60” & 72”)............. 2
19 800299 Screw, 3/8-16 x 2 3/4 .............. 1 45
633580 Seal, bearing........................... 4
20
633097 Hitch pin w/lanyard .................. 1
46
633585 Bearing cone........................... 4
21
806005 Hairpin cotter (serv only) ......... 1
47
633581 Spacer, bearing....................... 4
22
800295 Screw, 3/8-16 x 1 3/4............... 2
48
633582 Wheel & tire assy (52” Koh).... 2
23
303327 Washer, 3/8 disc spring...........12 633002 Tire,13x5.0-6 4
ply (52” Koh)... 2
24 809007 Nut, whizlock 3/8-16 ...............19
633583 Wheel (52” Koh)...................... 2
25
800292 Screw, 3/8-16 x 1..................... 3 633971 Wheel & tire assy
26
800293 Screw, 3/8-16X1 1/4 ................12 (52” Kaw, 60” & 72”) ............ 2
27
805271 Washer, 7/8 SAE flat.. ............. 4 523009 Tire, 13x6.5-6 4 ply
28
633096 Rod, deck lift............................ 2 (52” Kaw, 60” & 72”). ........... 2
29
804522 Nut, 5/8-11 regular .................. 8 633987 Wheel (52” Kaw, 60” & 72”)..... 2
30
633441 Swivel, deck mount.................. 4 633584 Bearing cup............................. 4
31
805268 Washer, 5/8 std flat................. 4
49
633587 Handle..................................... 1

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
