Exmark LAZER Z Parts Manual

5
60” DECK GROUP
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 632958 Deck wldmt, 60....................... 1 42 633447 Chain...................................... 4
634983 Deck wldmt, 60 w/decals........ 1 43 800811 Screw, 7/16-14 x 1-1/2 ........... 8
2 634619 Housing w/ring, spacer, brg.... 3 44 800271 Screw, 5/16-18 x 3/4 ............. 2
3 805259 Washer, 3/8 SAE.................... 3 45
•
303498 Sheave, blade drive 6.13 OD. 1
4 513208 Washer, disc Spring............... 6 46
•
633010 Pulley, split 6.30 OD
(23hp&25hp)
1
5 303334 Washer, 5/16 disc spring........ 1 643292 Pulley, split 6.71 OD
(26hp Koh)
1
6 809001 Nut, 5/16-18 whizlock ............. 14
47
◊
803046 Setscrew, 5/16-18 x 1sqhdcp. 1
7 602913 Baffle wldmt, discharge .......... 1
48
◊
803022 Setscrew,5/16-18x5/8sqhdcp 2
8 800270 Screw, 5/16-18 x 5/8............... 5 49 807264 Key, 1/4 sq x 2 5/8.................. 1
9 603299 Roller, antiscalp...................... 6 50 633012 Jackshaft, deck drive.............. 1
10 809007 Nut, 3/8-16 whizlock ............... 10 51
804522 Nut, 5/8-11 hex....................... 2
11 373034 Washer, pivot ......................... 7 52 800304 Screw, 3/8-16 x 3 1/4 ............. 1
12 603602 Bushing, roller......................... 6 53 633014 Bracket, jackshaft................... 1
13 303327 Washer, 3/8 disc spring.......... 10 54 807503 Bolt, 5/16-18 x 3/4 Carr. ........ 6
14 800807 Screw, 3/8-16 x 4 gr 8 .......... 6 55 513013 Housing, flange ...................... 4
15 632939 Chute, discharge 60” .............. 1 56 513012 Bearing w/lock collar & ss ...... 2
16 800273 Screw, 5/16-18 x 1.................. 3
57
∗
634972 Cutter housing complete ........ 3
17 804256 Nut, 5/16-18 nylock................. 4 58 807507 Bolt, 3/8-16 x 1 carr................ 4
18 633084 Shield, belt 60”........................ 2 59 632690 Strut wldmt, deck.................... 2
19 323385 Knob, belt shield..................... 6 60 323533 Spacer shv/brg ....................... 3
20 322110 Belt guide wldmt ..................... 1 61 633029 Spherical rod end ................... 2
21 800848 Screw, 5/8-11 x 1 gr 8 ............ 3
62
◊
803050 Setscrew, 5/16 x 3/4sqhdcp ... 1
22 800297 Screw, 3/8-16 x 2 1/4.............. 2 63
800343 Screw, 5/8-11 x 5 ................... 2
23 303537 Stud, belt shield...................... 2 64
805010 Lockwasher, 5/8 reg.spring .... 2
24 805258 Washer 5/16 std flat ............... 4 65
811006 Zerk, 1/4-28 straight ............... 4
25 323417 Washer, rubber....................... 2 66
632199 Pin wldmt, deck strut .............. 2
26 633151 Spring, extension.................... 1 67
804510 Nut, 5/8-18 hex....................... 5
27 632119 Arm wldmt, deck idler............. 1 68
807006 Key, # 61 Woodruff................. 3
28 513034 Bearing, pivot.......................... 2 69
•
633701 Sheave, Blade drive. .............. 3
29 634244 Arm wldmt/brg sub-assy......... 1 70
513016 Bearing ................................... 6
30 603044 Bushing, idler pivot ................. 1 71
323532 Housing, bearing .................... 3
31
811008 Zerk, 1/4-20 90
°
...................... 1
72
323528 Spacer, bearing ...................... 3
32 805260 Washer, 3/8 std flat ................ 1 73
633573 Guard, brg bottom .................. 3
33 804257 Nut, 3/8-16 nylock................... 20 74
808502 Snap Ring............................... 3
34 800299 Screw, 3/8-16 x 2 3/4.............. 1 75
633942 Spindle.................................... 3
35 633109 Idler pulley 6.00 dia flat........... 2 76
633483 Blade, notched air foil............. 3
36 803016 Bolt, 3/8-16 x 1 whizlock......... 1
613250 Blade, solid air foil .................. 3
37 633456 Bushing, Idler.......................... 2
613111 Blade, low lift .......................... 3
38 800293 Screw, 3/8-16 x 1 1/4.............. 18
✦
613112 Blade, mulching...................... 3
39 809073 Nut, 7/16-14 whizlock ............. 16 77 634546 Jackshaft S/A ......................... 1
40 603805 Idler pulley 5.06 O.D. V........... 1
78 634726 Strut wldmt S/A....................... 2
41 633127 Belt, blade drive 60” deck....... 1
634772 Strut wldmt S/A (26hp Koh).... 2
✦
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK604
•
Use antiseize on bore of sheaves.
◊
Use Pro-lock Nut Type (P/N 840022 .5 ml. tube) on setscrews.
Exmark red touch up spray paint - P/N 850337
∗
Cutter housing complete includes sheave, washer, and nut.
