Exmark LAZER Z Parts Manual

27
DECAL GROUP
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 633792 Decal, Console 1..................... 1
21 643339 Decal, Pump Belt Rtg ............. 1
2
633798 Decal, Console 2..................... 1
22
633354 Decal, Motion Control ............. 2
3
633702 Decal, Check Service.............. 1
23
643082 Decal, Commercial 72 ............ 1
4
633462 Decal, Important...................... 1
24
513748 Decal, Guard........................... 2
5
403005 Decal, Danger ......................... 2
25
633827 Decal, Park Brake Warning.... 1
6
323540 Decal, Roller Mounting............ 1
26
513747 Decal, Battery ......................... 1
7
633706 Decal, Deck Height ................ 1
27
643252 Decal, Belt Drive Warning....... 1
8
643222 Decal, Belt Routing ................. 1
28 633345 Decal, Deck Height................. 1
9
513742 Decal, No Step........................ 2
29
303508 Decal, Discharge Warning...... 1
10
613050 Decal, Commercial 60............. 1
30*
643103 Decal, Exmark logo................. 2
11 303293 Decal, 2 Minute Cool............... 2
•
643103 Decal, Exmark logo................. 1
12
♦
633346 Decal, Fuel Valve.................... 1
31
643289 Decal, Patent No..................... 1
13
373066 Decal, Patent Pending ............ 2
32*
633770 Decal, Hot Surface.................. 2
14
633313 Decal, Warning ....................... 1
33*
643104 Decal, L.C. Lazer Swash ........ 2
15 513929 Decal, Drive Release .............. 1
34
•
643288 Decal, Fuse/Relay................... 1
16 403132 Decal, Commercial 52............. 1
35*
643253 Decal, Radiator Fan................ 1
17 303520 Decal, TriVantage (52”&60”)... 1
36
•
643233 Decal, Fuel Valve-Dual ........... 1
643140 Decal, TriVantage (72”)........... 1
634976 Decal Kit-Kohler Air-Cooled
18 523552 Decal, Hyd Tank/Hot Surface . 1 644156 Decal Kit-Kawasaki Liquid
-
Cooled
19** 633350 Decal, Lazer Swash ................ 2
644318 Decal Kit-26 HP EFI Kohler
20 633922 Decal, Anti-Scalp..................... 1
* Decals for Kawasaki Liquid-Cooled units only.
** Decal for Kohler Air-Cooled units only.
♦
Decal for all units except 26 HP EFI Kohler.
•
Decals for 26 HP EFI Kohler units only.

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
