Exmark LAZER Z Parts Manual

3
52” DECK GROUP
Ref.
No.
Qty.
.Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 642053 Deck wldmt
,
52" ......................1 41 633366 Belt
,
blade drive 52” Deck.......1
634536 Deck wldmt, 52" w/decals .......1 42 633447 Chain.......................................4
2 805259 Washer, 3/8 SAE.....................3 43 800811 Screw, 7/16-14 x 1-1/2............8
3 323533 Spacer, shv/brg.......................3 44 800271 Screw, 5/16-18 x 3/4 ..............2
4 513208 Washer, disc spring ................6 45
•
403087 Sheave, blade drive 6.75 OD..1
5 303334 Washer, 5/16 disc spring ........1 46
•
633010 Pulley, split sheave 6.30 OD...1
6 809001 Nut, 5/16-18 whizloc................14
47
◊
803046 Setscrew, 5/16-18 x 1sqhdcp..1
7 602913 Baffle wldmt, discharge...........1
48
◊
803022 Setscrew,5/16-18x5/8sqhdcp .2
8 800270 Screw, 5/16-18 x 5/8 ...............5 49 807264 Key, 1/4 sq x 2 5/8 ..................1
9 603299 Roller, antiscalp.......................6 50 633012 Jackshaft, deck drive ..............1
10 809007 Nut, 3/8-16 whizlock................12
51
∗
634620 Cutter housing complete.........3
11 373034 Washer, pivot ..........................7 52 800304 Screw, 3/8-16 x 3 1/4..............1
12 603602 Bushing, roller .........................6 53 633014 Bracket, jackshaft ...................1
13 303327 Washer, 3/8 disc spring ..........10 54 807503 Bolt, 5/16-18 x 3/4 Carr..........6
14 800807 Screw, 3/8-16 x 4 gr 8 ............6 55 513013 Housing, flange.......................4
15 602571 Chute, discharge 52”...............1 56 513012 Bearing w/lock collar & ss.......2
16 800273 Screw, 5/16-18 x 1 ..................3 57 633573 Guard, Brg bottom ..................3
17 804256 Nut, 5/16-18 nyloc ...................4 58 807507 Bolt, 3/8-16 x 1 carr.................4
18 633357 Shield, belt 52” ........................2 59 632690 Strut wldmt, deck ....................2
19 323385 Knob, belt shield......................6 60 634619 Housing w/ring, spacer, & brg .3
20 322110 Belt guide wldmt......................1 61 633029 Spherical rod end....................2
21 800848 Screw, 5/8-11 x 1 gr 8 .............3
62
◊
803050 Setscrew, 5/16-18 x .75sqhd ..1
22 800297 Screw, 3/8-16 x 2 1/4 ..............2 63
800343 Screw, 5/8-11 x 5....................2
23 303537 Stud, belt shield.......................2 64
805010 Lockwasher, 5/8 reg.spring.....2
24 805258 Washer 5/16 std flat................4 65
811006 Zerk, 1/4-28 straight................4
25 323417 Washer, rubber .......................2 66
632199 Pin wldmt, deck strut...............2
26 633151 Spring, extension.....................1 67
804510 Nut, 5/8-18 hex .......................5
27 632119 Arm wldmt, deck idler..............1 68
807006 Key, # 61 Woodruff.................3
28 513034 Bearing, pivot ..........................2 69
•
633701 Sheave, blade drive ................3
29 634244 Arm wldmt/brg sub-assy..........1 70
513016 Bearing....................................6
30 603044 Bushing, idler pivot..................1 71
323532 Housing ,bearing.....................3
31
811008 Zerk, 1/4-20 90
°
. .....................1
72
323528 Spacer, bearing.......................3
32 805260 Washer, 3/8 std flat.................1 73
800293 Screw, Hex cap 3/8 x 1 1/4.....18
33 804257 Nut, 3/8-16 nylock ...................20 74
808502 Snap Ring ...............................3
34 800299 Screw, 3/8-16 x 2 3/4 ..............1 75
633574 Spindle....................................3
35 633109 Idler pulley 6.00 dia flat............2 76
633482 Blade, notched air foil. ............3
36 803016 Bolt, 3/8-16 x 1 whizlock..........1
613251 Blade, solid air foil...................3
37 633456 Bushing, Idler ..........................2
633485 Blade, low lift...........................3
38
804522 Nut, 5/8-11 hex........................2
✦
633484 Blade, mulching ......................3
39 809073 Nut, 7/16-14 whizlock..............16 77
634546 Jackshaft S/A..........................1
40 603805 Idler pulley 5.06 O.D V ............1
78
634726 Strut wldmt S/A .......................2
✦
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK523
•
Use antiseize on bore of sheaves.
◊
Use Pro-lock Nut Type (P/N 840022 .5 ml. tube) on setscrews.
Exmark red touch up spray paint - P/N 850337
∗
Cutter housing complete includes sheave, washer, and nut.

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
