Exmark LAZER Z Parts Manual

25
HYDRAULIC GROUP
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 403102 Hose, Lower 52” & 60”............. 2 26 632285 Hose, low pressure (11 1/4”) .. 1
2
∇
512166 Tank, hydraulic reservoir......... 1
27
632286 Hose, low pressure (4”) .......... 1
3
∇
513006 Head, filter............................... 1
28
633568 Sheave, pump ........................ 2
4
513034 Bearing, pivot.......................... 2
29
633567 Sheave, engine....................... 1
5
513167 Cap, hydraulic tank ................. 1
30 633569 Belt, pump drive...................... 1
6
513211 Element, hydraulic oil filter ...... 1
31 633167 Pulley, idler w/bushing............ 1
♦
523541 Element, hyd oil filter(winter)... 1
32
633335 Hose, low pressure (14 1/2”) .. 2
7
513840 Elbow, 90
°
w/O-ring ................ 2
33
634277 Arm, w/bearing ....................... 1
603921 O-Ring..................................... 1
34
800252 Screw, 1/4-20 x 3/4................. 2
8
522217 Hose, low pressure (7”)........... 1
35
800294 Screw, 3/8-16 x 1 1/2.............. 1
9
523103 Gasket, tank cap..................... 1
36
800295 Screw, 3/8-16 x 1 3/4.............. 1
10
523222 Elbow, 45
°
(w/O-rings)............ 4
37
800805 Screw, 3/8-16 x 3 1/2.............. 1
603919 O-Ring (SAE #10)................... 1
38
800293 Screw, 3/8-16 x 1.................... 4
603992 O-Ring (37
°
flare #8)............... 1 39
◊
803022 Setscrew, 5/16-18 x 5/8.......... 2
11
523328 Motor, wheel drive................... 2
40
◊
803046 Setscrew, 5/16-18 x 1............. 2
000099 Kit, seal ................................... 1
41
◊
803050 Setscrew, 5/16-18 x 3/4.......... 2
000139 Kit, bearing.............................. 1
42
805004 Lockwasher, 1/4 ..................... 2
12
603384 Bushing, idler pivot.................. 1
43
805258 Washer, 5/16 std .................... 1
13
603413 Spring, pump drive idler.......... 1
44
805260 Washer, 3/8 std ...................... 1
14
603721 Fitting, tee (3/8” i.d. hose)....... 1
45
807263 Key, 1/4 x 1/4 x 1 1/4.............. 1
15
603722 Fitting, tee (1/4” i.d. hose)....... 1
46
807272 Key, 5mm x 5mm x 25mm ..... 2
16
603826 Clamp, hose (1/2”) .................. 3
47
809007 Nut, 3/8-16 whizlock ............... 8
17
603827 Clamp, hose (5/8”) .................. 5
48
809012 Nut, whizlock 1/4-20 ............... 2
18
603987 Elbow, 90
°
7/16-JIC x 1/4-NPT 1
49
811008 Zerk, 90
°
1/4-28...................... 1
19
603988 Elbow, 90
°
9/16-JIC x 1/4-NPT 1
50
800251 Screw, 1/4-20 x 5/8................. 2
20
603989 Elbow, 90
°
(w/O-ring).............. 2
51
603841 Pump, hydro ........................... 2
603923 O-Ring (SAE #4)..................... 1 2513018 Kit, overhaul seal .................... 1
21
603990 Connector, strght. (w/O-rings) 4
52
633786 Elbow, 90
°
(w/O-rings)............. 4
603920 O-Ring (SAE #8)..................... 1 603919 O-Ring (SAE #10)................... 1
603992 O-Ring (37
°
flare #8)............... 1 603992 O-Ring (37
°
flare #8) .............. 1
22
613034 Hose, high pressure 60”.......... 2
53
633775 Hose, lower (52”&60”) ............ 2
403102 Hose, high pressure 52" ......... 2 633777 Hose, lower (72”).................... 2
23 632201 Arm, pump idler ...................... 1 54
633774 Hose, upper (52”&60”)............ 2
24 632281 Hose, low pressure (12”)......... 1 633776 Hose, upper (72”) ................... 2
25 632282 Hose, low pressure (20 1/2”)... 1
◊
Use Pro-Lock, Nut Type (P/N 840022, 5 ml tube) on setscrews.
∇
Use Teflon pipe sealant on pipe threads in reservoir & filter head.
Exmark black touch up spray paint - gloss black
♦
Use only for operation below 32
°
F (0
°
C)
