Exmark LAZER Z Parts Manual

23
KAWASAKI LIQUID-COOLED ENGINE DECK GROUP (cont.)
Ref.
No.
Qty.
.Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 633864 Screen, Radiator Intake .......... 1 31 809007 Nut, Whizlock 3/8-16 ............. 10
2
803069 Screw, 10-24X.75 BHSCap..... 4
32
633897 Rib, Top .................................. 2
3
805252 Washer, Flat Std #10 .............. 16
33
633898 Rib, Bottom............................. 2
4 804252 Nut, Nyloc #10-24 ................... 4 34
633877 Bar, Latch Hook...................... 2
5
633857 Hood, Engine Gray................. 1
35
643189 Keeper, Rubber Latch............. 2
6
800272 Screw, Cap Hex 5/16-18x7/8.. 8
36 633896 Bar, Rad. Mnt. Frame............. 2
7
805257 Washer, Flat SAE 5/16 ........... 21
37
800293 Screw, Cap Hex 3/8-16x1-1/4. 4
8 804256 Nut, Nyloc 5/16-18 .................. 4 38
800256 Screw, Cap Hex1/4-20x1 1/2.. 2
9
633885 Plate, Hood Hinge................... 2
39
633901 Plate, Side Rad. Mnt. RH........ 1
10
632986 Hinge, Shackle wld.................. 2
40
632984 Radiator Brace wldmt-LH........ 1
11
809001 Nut, Whizlock 5/16-18 ............ 37
41
632985 Radiator Brace wldmt-RH....... 1
12
800271 Screw, Cap Hex 5/16-18x3/4.. 24
42
633878 Crossbar ................................. 1
13
808285 Pin, Clevis 3/8x1 1/8 ............... 2
43
643087 Deflector, Air........................... 1
14 805259 Washer, Flat SAE 3/8 ............. 12 44
803010 Pop Rivet- Stl 3/16x.250......... 4
15
806003 Pin, Hair Cotter .080 #2........... 2
45
809086 Screw, Tapping1/4-20x.75...... 2
16
643106 Angle, Rad. Trim Side RH....... 1
46
643096 Plenum, Air intake................... 1
17
643108 Angle, Rad. Trim Bottom......... 1 47 643147 U-bolt ...................................... 2
18
643107 Angle, Rad. Trim Top.............. 1
48
643150 Weight Bar (60” deck)............. 3
19
643105 Angle, Rad. Trim Side LH ....... 1 643150 Weight Bar (52” deck)............. 4
20
643187 Seal, Trim - 20" Length............ 2
49
805260 Washer, flat Std 3/8................ 4
21
643186 Seal, Trim - 14" Length............ 2
50
804257 Nut, Nyloc 3/8-16 .................... 4
22 633900 Plate, Side Rad. Mnt. LH......... 1 51
634308 Shield, lift - subassembly........ 1
23
643188 Latch, EPDM Rubber .............. 2
52
633300 Shield, lift ................................ 1
24
803056 Pop Rivet................................. 8
53
803035 Rivet, Alum. 3/16x1/4.............. 3
25
800273 Screw, Cap Hex 5/16-18x1..... 9
54
633298 Shield, engine......................... 1
26 632873 Radiator Mount weld-rear........ 1 55
809012 Nut, Whizlock 1/4-20 .............. 2
27 633886 Bumper, Rear.......................... 1 56
800252 Screw, 1/4-20x3/4................... 4
28
804255 Nut, Nyloc 1/4-20 .................... 6
57
805256 Washer, 1/4 std ...................... 6
29
800292 Screw, Cap Hex 3/8-16x1 ....... 6
58
803072 Rivet, Bulbex .19 x1.07 .......... 17
30
523420 Bumper, rubber....................... 2
59
303435 Washer, Spring Disc .25 ........ 5
