Exmark LAZER Z User Manual

Maintenance
CheckEngineStartingCircuitChart
Note:IntheCheckEngineStartingCircuitChart,thestateofsystemitemthatisboldisbeingchecked
ineachscenario.
System
ParkingBrake
PTO
(Blades)
MotionControlLeversOperatorOutcome
EngagedDisengaged
Bothleversmovedin,oreither
rightorleftlevermovedin
Operator
inseat
Startermust
notcrank
Disengaged
Disengaged
Bothleversout(neutrallock)
Operator
inseat
Startermust
notcrank
Stateof
System
CheckShutdownCircuitChart
Note:Thestateofsystemitem(s)thatisboldisbeingcheckedineachscenario.
System
EngineParking
Brake
PTO
(Blades)
MotionControl
Levers
OperatorOutcome
Runningidle
(1/3throttleor
efcientmode)
DisengagedDisengaged
Bothleversmoved
out(neutrallock)or
bothleversmovedin
Raiseoff
ofseat(but
don’tgetoff)
Enginemust
beginshutdown
within1second
State
of
System
58

Exmark LAZER Z Specifications

General

Engine Brand	Kawasaki
Transmission	Hydrostatic
Deck Construction	Fabricated or welded steel
Category	Commercial
Type	Commercial
Speed	10 mph
Turning Radius	Zero-turn
Fuel Capacity	10-15 gallons
Weight	1, 465 lbs
