Exmark Phazer 4500-461 - Seat Group

SEAT GROUP
-9-
Item Part No. Description Qty.
1 27-0410 Screw, Shoulder 5/16-18 x 1 Sp.............2
2 63-8410 Washer ..................................................4
3 82-2190 Switch ....................................................1
4 103-3999 Decal, Exmark Logo...............................1
5 103-9376 Bumper, Seat......................................... 2
6 104-8300 Nut, Nyloc 5/16-18 Flg ........................... 4
7 109-3128 Asm, Seat W/Decals .............................. 1
8 109-2427-03 Bar, Seat Stop........................................1
Item Part No. Description Qty.
9 116-0950 Decal, Service Aid ................................. 1
10 109-2607-03 Bracket, Seat ......................................... 1
11 109-2608 Spacer ................................................... 4
12 108-6163 Kit, Armrest............................................ 1
13 32144-4 Screw, HWH 1/2-20 x 1/2 Taptite........... 2
14 322-10 Screw, HH 5/16-18 x 2........................... 4
15 1-653036 Washer .................................................. 4
Exmark black touch up spray paint – gloss black.
