Operation
themachinehastobepushedbyhand,thevalves
mustbeinthe“released”position(seeFigure9).
Figure9
1.Frontofthemachine
2.Rotatebypassreleaseknobcounterclockwisetoloosen
3.Leverpositionforoperatingthemachine
4.Pullleverinthisdirectiontopushthemachine
5.Leverpositionforpushingthemachine
6.Rotatebypassreleaseknobclockwisetotighten
7.Engine
8.Releaselever
Toreleasethedrivesystem(seeitem1inFigure9),
loosentheknobbyturningcounterclockwise.Then
pullthereleaseleverontheundersideofmachine
towardsthebackofthemachineandretightenthe
knobtoholdthereleaseleverbackinthereleased
state.Repeatthisoneachsideofthemachine.
Releasetheparkingbrake.Themachineisnowable
tobepushedbyhand.
Toresetthedrivesystem(seeitem2inFigure9),
loosentheknobbyturningcounterclockwise.Then
pushthereleaseleverontheundersideofmachine
towardsthefrontofthemachineandretightenthe
knobtoholdthereleaseleverintheoperatingstate.
Repeatthisoneachsideofthemachine.
DoNottowmachine.
PTOEngagementSwitch
Locatedonrightconsole(seeFigure6).
Switchmustbepulledout(up)toengagetheblades.
Switchispushedintodisengagetheblades.
DeckLiftPedal
Locatedattherightfrontcorneroftheoorpan.
Pushthepedalforwardwithyourfoottoraisethe
cuttingdeck.Allowthepedaltomoverearwardto
lowerthecuttingdecktothecutheightthathasbeen
set.
Figure10
1.Transportlockknob
3.Heightofcutdecal
2.Heightadjustmentpin
4.Deckfootpedal
TransportLock
LocatedonRHconsoleinfrontofthemotion
controllever(seeFigure10).
Thetransportlatchingmechanismwillautomatically
engagewhenthedeckisraisedtothetransport
position.Toreleasethedeckfromthetransport
position:pushthefootpedaltoremovetheload
fromthetransportlatchingmechanism,pullupon
thetransportlockknob,andletthepedalcomeback
tolowerthedeckdowntothedesiredcutheight.
Pre-Start
Fillfueltankonlevelground.SeeFuel
RecommendationsintheSpecicationssectionfor
additionalgasolineinformation.
26

Exmark RADIUS Specifications

General

Transmission	Hydrostatic
Turning Radius	Zero-turn
Engine	Kawasaki
Cutting Width	48, 52, 60 inches
Weight	805 - 895 lbs
