Operation
•RearDischargeUnits:
Torquethe3/8nylocnutto30-35ft-lb(41-47
N-m)(seeFigure19).
Figure19
1.3/8inchnyloc-torqueto
50-55ft-lb(68-75N-m)
3.Wheelspacer
2.Anti-scalprollers
4.3/8-16X73/8inchbolt
Note:Thefootoperateddeckliftassistlevercanbe
usedtomomentarilyliftthedecktoclearobjects.Be
surethatPTOisdisengaged.
AdjustingtheSideBumpers
(RearDischargeUnitsOnly)
Mountthesidebumpersinthetopholeswhen
operatinginheightofcutshigherthan21/2inches
(64mm)andinthecenterholeswhenoperatingin
heightofcutslowerthan21/2inches(64mm).
Note:Whenbumpersbecomeworn,switchthe
bumperstotheoppositesidesofthemower,ipping
themover.Thisallowsthebumperstobeusedlonger
beforereplacingthem.
1.Stopthemachineandmovethemotioncontrol
leversoutwardtotheneutrallockedposition.
2.DisengagethePTO.
3.Engagetheparkbrake.
4.Stoptheengine,removethekeyandwaitforall
movingpartstostop.
5.Positionthetransportlockinthelatching
position.
6.Removetheboltsandnutsfromeachbumper.
Figure20
1.Bolt3.Nut
2.Bumper
7.Moveeachbumpertothedesiredpositionand
securethemwiththeboltsandnuts.
Note:Onlyusethetoporcentersetsofholesto
adjustthebumpers.Thebottomholesareused
whenswitchingsides,atwhichtimetheybecome
thetopholesontheothersideofthemower.
Transporting
TransportingtheMachine
Useaheavy-dutytrailerortrucktotransportthe
machine.Ensurethatthetrailerortruckhasall
necessarylightingandmarkingasrequiredbylaw.
Thoroughlyreadallofthesafetyinstructions.
Knowingthisinformationcouldhelpyou,your
family,pets,orbystandersavoidinjury.
Totransportthemachine:
•Lockthebrakeandblockthewheels.
•Besurethefuelshut-offvalveisclosed.
•Securelyfastenthemachinetothetraileror
truckwithstraps,chains,cable,orropes.Only
usethefourdesignatedtie-downlocationson
themower–twoontheleftsideandtwoonthe
right(seeFigure21).Usetheselocationseven
whentransportingthemowerwithanattached
accessory.Usingnon-designatedlocationsmay
causedamagetothemowerand/orattachment.
32
