Exmark RADIUS - Adjusting the Seat Ride Suspensions-Series Only; Electric Clutch Adjustment

Maintenance
Figure73
1.Nut4.Returntoneutralplate
2.Stationaryplate
5.Tabstouchingreturnto
neutralplate
3.Controlplate
8.Shutoffunit.Removejumperwirefromwire
harnessandplugconnectorintoseatswitch.
9.Removethejackstands.
10.Raisethedeckandre-installtheheightofcutpin.
11.Checkthatthemachinedoesnotcreepinneutral
withtheparkbrakedisengaged.
AdjustingtheSeat
RideSuspension
S-SeriesOnly
Theseatisolatorcanbechangedtomaximizerider
comfort(seeFigure74).
•Forarmerride,movethesearisolatorrearward.
–usedforoperators200lb(91kg)andover
–mowingroughterrain
•Forasofterride,movetheseatisolatorforward.
–usedforoperatorslessthan200lb(91kg)
–mowingsmooth,wellestablishedlawns
Figure74
1.Seatisolator
ElectricClutchAdjustment
Noadjustmentnecessary.
