- 10 -
2.7 TRANSMISSION:
Twin Hydrostatic Drive
2.7.1 Two Hydro Gear BDP-10L series variable displacement efficiency pumps
independently coupled to two high effeciency Parker/Ross wheel drive motors.
2.7.2 Hydraulic Filter is replaceable cartridge type.
P/N 513211: 10 microns, 18 psi bypass (Summer use above 32°
F)
P/N 523541: 40 microns, 18 psi bypass (Winter use below 32°
F)
2.7.3 Speed Range: Forward 0 - 6.2 mph (10.0 km/h)
Reverse 0 - 2.2 mph (3.5 km/h)
2.8 WHEEL DRIVE SYSTEM:
Drive wheels are direct coupled to Parker/Ross wheel drive motors with 1.0"
(25.4 mm) tapered shaft.
2.9 TIRES
Drive Front Caster
Size.................16 x 6.50-8...........................9 x 3.50-4
Quantity...................... 2.........................................2
Tread ......... Turf Saver/Turf Master.................. Smooth
Ply Rating................... 4.........................................4
Pressure........ 14 psi (97 kPa)................. 22 psi (152 kPa)
2.10 DECK
2.10.1 Cutting Width:
Model 36 in. ........................................35.25 in. (89.5 cm)
Model 48 in. ........................................47.25 in. (120.0 cm)
Model 52 in. ........................................52.00 in. (132.1 cm)
2.10.2 Discharge: Right Side
2.10.3 Blade Size:
Model 36 in. ..............18.00 in. (45.7 cm) ..............Qty. 2
Model 48 in. ..............16.25 in. (41.3 cm) ..............Qty. 3
Model 52 in. ..............18.00 in. (45.7 cm) ..............Qty. 3
2.10.4 Type of Drive: Manual engagement of belt with over-center lock. Belt tension
is adjustable via turnbuckle.
2.10.5 Deck Mounting: Full floating deck is attached to out-front support frame,
removable for service.
2.10.6 Cutting Height: Adjusts in 1/2” (.63 cm) increments from 1.5” (3.8 cm) to 4 1/2”
(11.4 cm).
