2.11 DIMENSIONS
2.11.1 Overall Width: 36” 48” 52”
Discharge chute down
46.25” 58.25” 62.6”
(117.5 cm) (148.0 cm) (159.0 cm)
Discharge chute up
36.1” 48.1” 53.0”
(Transport only)
(91.7 cm) (122.2 cm) (134.62 cm)
2.11.2 Overall Length: 36” 48” 52”
Overall Length
77.7” 73.7” 75.9”
(197 cm) (187 cm) (193 cm)
2.11.3 Curb Weight: 36” 48” 52”
Curb Weight
∗
518 lbs. 566 lbs. 594 lbs.
(235 kg) (257 kg) (269 kg)
∗ Weights will vary slightly depending on engine option.
2.11.4 Overall Height: 42” (107 cm)(all units)
2.11.5 Tread Width (to outside of tires):
36” Model....................35.0” (88.9 cm)
48” Model....................38.7” (98.3 cm
52” Model....................38.7” (98.3 cm)
2.12 TORQUE REQUIREMENTS
BOLT LOCATION TORQUE
Blade Mounting Bolt ......................................................... 75-80 ft-lbs.
Cutter Housing Spindle Nut.............................................. 75-80 ft-lbs.
Anti-Scalp Roller Bolts...................................................... 40-45 ft-lbs.
Mower Deck Support/Engine Deck Mount........................ 30-35 ft-lbs.
Engine Mounting Bolts
15 &17
HP
Kawasaki & Briggs
&
Stratton
.......... 15-20 ft-lbs.
Kohler
&
14
HP
Kawasaki .................................. 25-30 ft-lbs.
3. ASSEMBLY INSTRUCTIONS
3.1 Uncrate unit, and remove upper handle assembly, fuel tank, and linkages from
the top of the crate.
3.2 Remove and open the bolt bag.
3.3 Loosen the 5/16" hardware at the two (2) discharge chute hinge points so that
the deflector is snug, but can be moved up and down freely.
3.4 Refer to Parts Manual to help you identify and locate parts and their proper
position.
3.5 Apply retaining adhesive “Fel-Pro ProLock Retaining I or Retaining II” or “Loctite
RC 609 or 680” on the two threaded studs from the bolt bag and install into the
two left holes underneath fuel tank. Install the fuel tank on top of the fuel tank
support with the studs going through the slots in the support. Install two 5/16 x
3/4 screws with a 5/16 SAE flatwasher and 5/16 lockwasher into the threaded
holes in the right side of the fuel tank.
Do not over tighten
. Place a 5/16 SAE
flatwasher, then a spring, over each of the studs and fasten with a 5/16 nyloc
nut. Tighten 5/16 nyloc nut fully then back off a 1/2 turn. This is to allow for
normal fuel tank expansion and contraction with changes in temperature and fuel
levels.
Do not over tighten
.
To Next Page
