Exmark VANTAGE X Series User Manual

Specications
•HydraulicOil:UseExmarkPremiumHydroOil.
•HydraulicOilCapacity:2.4qt.(2.2L)
•HydraulicFilterisreplaceablecartridgetype.
P/N109-4180:25microns,10psibypass
(Summeruseabove32°F(0°C))
P/N1-523541:40microns,18psibypass(Winter
usebelow32°F(0°C))
•Speeds:
–0-8.0mph(13km/hr)forward.
–0-4.0mph(6km/hr)reverse.
•Drivewheelreleasevalvesallowmachinetobe
movedwhenengineisnotrunning.
WheelDriveSystem
DrivewheelsaredirectcoupledtoParkerwheeldrive
motorswith11/4inch(31.8mm)taperedshaft.
Tires&Wheels
Drive
FrontCaster
Pneumatic
(Air-Filled)
Semi-
Pneumatic
Quantity
22
Tread
K500
Smooth
Size20x10.50–811x4.00-5
PlyRating
4
Pressure
13psi
(90kPa)
CuttingDeck
•CuttingWidth:
–48inchDeck:48inches(121.9cm)
–52inchDeck:52inches(132.1cm)
–60inchDeck:60inches(152.4cm)
•Discharge:Side
•BladeSize:(3ea.)
–48inchDeck:16.25inches(41.3cm)
–52inchDeck:18.00inches(45.7cm)
–60inchDeck:20.50inches(52.1cm)
•BladeSpindles:Solidsteelspindleswith1.00inch
(25.4mm)I.D.bearings.
•DeckDrive:
–Electricclutchmountedonengineshaft.
–Bladesdrivenbyonebelt(w/self-tensioning
idlers).
•Deck:Fulloatingdeckisattachedtosupport
frame,removableforservice.Deckdesignallows
forbagging,mulchingorsidedischarge.
•DeckDepth:
–48inchDeck:5.5inches(14.0cm)
–52inchDeck:5.5inches(14.0cm)
–60inchDeck:5.5inches(14.0cm)
•CuttingHeightAdjustment:Adjustsfrom1inch
(2.5cm)to5.5inches(14cm)in1/4inch(6.4
mm)increments.
•MulchingKit:Optional
•Bagger:Optional
Dimensions
OverallWidth:
48inch
Deck
52inch
Deck
60inch
Deck
Deector
Up
51.8inches
(131.6cm)
56.3inches
(143.0cm)
63.9inches
(162.3cm)
Deector
Down
59.6inches
(151.4cm)
64.8inches
(164.6cm)
72.8inches
(184.9cm)
OverallLength:
48inch
Deck
52inch
Deck
60inch
Deck
Platform
Up
60.5inches
(153.7cm)
60.5inches
(153.7cm)
62.4inches
(158.5cm)
Platform
Down
74.0inches
(188.0cm)
74.0inches
(188.0cm)
75.9inches
(192.8cm)
OverallHeight:
48inchDeck52inchDeck60inchDeck
50.0inches
(127.0cm)
50.0inches
(127.0cm)
50.0inches
(127.0cm)
TreadWidth:(OutsidetoOutsideof
Tires,Widthwise)
48inchDeck52inchDeck60inchDeck
46.5inches
(118.1cm)
46.5inches
(118.1cm)
50.5inches
(128.3cm)
17
