Exmark VANTAGE X Series User Manual

ProductOverview
CurbWeight:
48inchDeck52inchDeck60inchDeck
855lb
(388kg)
875lb
(397kg)
883lb
(401kg)
Note:Weightswillvaryslightlydependingonengine.
TorqueRequirements
BoltLocation
Torque
CutterHousingSpindle
Nut
130-160ft-lb
(176-217N-m)
BladeMountingBolt
(lubricatewithanti-seize)
50-60ft-lb(68-81N-m)
ClutchMountingBolt
50-60ft-lb(68-81N-m)
EngineDeck/Mower
DeckSupportMount
Bolts
30-35ft-lb(41-47N-m)
EngineMountingBolts
Kawasaki
Kohler
30-35ft-lb(41-47N-m)
27-33ft-lb(37-45N-m)
WheelLugNuts
85-105ft-lb(115-142
N-m)
WheelHubNuts175-225ft-lb
(237-305N-m)
WheelMotorMounting
Bolts
67-83ft-lb(91-113N-m)
HydroPumpRelease
Valves
110-130in-lb(12-15N-m)
ProductOverview
Figure3
1.Platform
4.Drivelevers
2.FuelCap5.EngineControls
3.Height-of-Cut
Adjustment
6.ParkBrakeLever
