Specications
Specications
ModelNumbers
SerialNos:920,000andHigher
VT20KA484;VT24KA484;VT24KA484CA;VT24KA524;VT24KA524CA;VT25EKC524
Systems
Engine
•EngineSpecications:SeeyourEngineOwner’s
Manual
•EngineOilType:Exmark4–CyclePremium
EngineOil
•RPM:FullSpeed:3600±100RPM(NoLoad)
FuelSystem
•Capacity:8.0gal.(30.2L)
•TypeofFuel:Regularunleadedgasoline,87
octaneorhigher;containingnomorethan10%
methanolorethanol.
•FuelFilter:
–Kawasaki:
KawasakiP/N49019-7005
–KohlerEFI:
KohlerP/N2505042
•FuelShut-OffValve:1/4turnincrements
ElectricalSystem(ElectricStart)
•ChargingSystem:FlywheelAlternator
•ChargingCapacity:
Kawasaki:15amps
KohlerEFI:20amps
•BatteryType:BCIGroupU1
•BatteryVoltage:12Volt
•Polarity:NegativeGround
•Fuses:
–30ampmainfuse
–25ampchargingsystemfuse
–10ampPTOfuse
–15ampaccessoryfuse
SafetyInterlockSystem
•LCDindicatorsappearfortheparkbrake,drive
levers,andoperatorpresenceinthemessage
displayonthefrontcontrolpanel.
Note:BecausethePTOmustbedisengaged
tostarttheengine,theLCDindicatorwillnot
illuminateatthistime.
•PTOmustbedisengagedandmotioncontrol
leversinneutraltostartengine.(Itisnot
necessaryfortheoperatortobeontheplatform
tostarttheengine.)
•Mowerbladeswillstopiftherightsidemotion
controlleverismovedorreleasedintothePTO
disengageposition.
•Enginewillstopifthemotioncontrolleversare
movedfromtheneutralpositionwiththepark
brakeengaged.
OperatorControls
SteeringControl:Fingertipdrivecontrollevers
provideindependentspeedcontrol,brakingand
neutraltoeachdrivewheelformovingforwardor
reverse,stopping,andpowerturning.
Transmission
•TwoHydroGearvariabledisplacementhigh
efciencypumpsindependentlycoupledtotwo
highefciencyParker/Rosswheeldrivemotors.
•HydraulicOil:UseExmarkPremiumHydroOil.
•HydraulicOilCapacity:2.4qt.(2.2L)
•HydraulicFilterisreplaceablecartridgetype.
P/N109-4180:25microns,10psibypass
(Summeruseabove32°F(0°C))
P/N1-523541:40microns,18psibypass(Winter
usebelow32°F(0°C))
•Speeds:
–0-8.0mph(13km/hr)forward.
