4.3 DMX-SETTINGS
4.3.1 M-DMX: MODUS
Allows you to toggle the DMX-mode of the device "ON" or "OFF".
4.3.2 M-DMX: STARTADRESSE
Allows you to set the starting address of the first DMX channel from 1 to 507 (Standard 1). The five
followong channels are always reserved for the different DMX functions.
4.3.3 M-DMX: CUSTOMER
Allows you to select between the standard DMX control (Explo) or the special DMX control of the
company Pyroemotions (Pyroemotions).
4.3.4 M-DMX: CH5 VERS.
Allows you to set which version of the DMX channel 5 calculations should be used.
The new calculation (new) is the current method, and the one
described in this manual.
4.3.5 M-DMX: PROTOCOL
Allows you to set whether you want to use the standard DMX control (DMX 512) or the Easy DMX
mode (DMX EASY). A detailed guide of the Easy DMX mode can be found in the description of the
control methods.
