Explo X2 Wave Flamer - Head Variant (Front View)

8
3.3 HEAD VARIANT WITHOUT INTERNAL PUMPING UNIT (FRONT)
Components of the X2 Wave Flamer
1
Key switch
7
ON/OFF switch (Power)
2
Display and usage buttons
8
Fuze 12VDC
3
Status-LEDs
9
Connector for external pumping unit
4
Antenna socket
10
Power connector 100-230VAC Neutrik True-1
5
Programming socket
11
Fuze 230VAC
6
DMX-connector
1
2
9
8
7
3
5
10
4
6
11
