Explo X2 Wave Flamer - Technical Data; Optional Accessories; Usable Fluids Information

53
15 TECHNICAL DATA
X2 Wave Flamer
Measurements
560x335x365mm
Weight
27kg (empty Tank)
Power supply
100VAC-230VAC / 350W
Casing
Stainless steel
Fuel
Isopropylalcohol, Bio-Ethanol, ISOPAR™ / We recommend adding 2cl castor oil
per 10L fluid
Radio range
800m
Swivel radius
-105° to 105°
Effect height
10m (optional 5m nozzle available)
16 ACCESSORIES (AVAILABLE SEPARATELY)
Optional accessories for the X2 Wave Flamer
Power connection cable
To lead power through to the next device. Available in all lengths.
Tripod
Tripod for the X2 Wave Flamer. Diameter 35mm / 50kg load bearing.
5m nozzle
Nozzle for reduced flame height (4-5m).
Flight-Case
Flight Case for safe transportation of the Wave Flamers.
Dolly for Flight-Case
Dolly for up to three Flight-Cases (stacked).
Emergency shut off
Emergency shut off switch for immediate interruption of the power supply.
Tool to switch nozzles
Tool to easily change the nozzles of the Wave Flamer. 14mm socket nut long.
Bootloader cable
Programming cable to update the devices firmware.
Rain protection
Protective cover to protect the front panel from water.
Angle blockers
Mechanical angle blockers for the X2 Wave Flamer.
17 INFORMATIONS FOR USEABLE FLUIDS
To lubricate the system, we recommend adding 10-20mL
castor oild per 10L canister.
Recommended fluids are:
Bioethanol 99%, Isopropanol 99% (IPA), ISOPAR (G, H, L, M)
If non recommended fluids are used (especially coloured
fluids), damages to the system may occur, leading to a
voiding of the guarantee.
