Explo X2 Wave Flamer - Planning and Preparing a Show

26
Checklist before driving to your show location
Do I have the correct amount of Wave Flamers with me?
Do I have the correct nozzles with me?
Do I have enough liquid fuel with me?
Are the ignition electrodes clean and in the correct position?
Do I need further accessories? (Tripod, socket wrench, connection cables?)
Do I need mechanical angle blockers, and are they mounted already?
Do I have the needed controllers with me and programmed?
Have the devices been checked for function and leak tightness?
Optional: Has the automated show been tested?
Optional: Do I have the needed antennas with me?
If these questions can be answered with YES, you are one step closer to a successful show.
Devices and automated shows must be tested before their
use.
7 POSITIONING AND PREPARATION AT THE SHOW LOCATION
7.1 POSITIONING OF THE DEVICES
Generally the X2 Wave Flamer must have enough distance to all living beings and objects, so that
they may not be harmed or endangered by the use of the projector. The safety distances provided by
the manufacturer can be found in the chapter "Saftey" of this document. Generally the distances
provided by local authorities and safety personnel are to be adhered.
For positioning it is recommended to have the front panel face away from the audiences side. The X2
Wave Flamer must be placed on firm, even ground, or a suitable tripod with a minimum of 50Kg
bearing load.
7.2 POWER SUPPLY
Using the provided power cable, the X2 Wave Flamer can be connected to the 100V-240VAC power
supply. Please note that every projector has a power consumption of 350W. The power supply should
be suitable for the number of devices used. Should you use your selfmade, or store bought power
cables, make sure the cable diameter is is at least 1,5mm².
With a strong lead acid battery and a sinus inverter the X2 Wave Flamer can also be powered without
the need of a grid supply. We recommend using a separate sinus inverter with at least 1000W per X2
Wave Flamer.
