15
R
ROSETTA
DIMENSION SKETCH
ROSETTA DISPLAY CONTROL 3GR
A
C
D
B
Model A B C D
ROSETTA 3Gr
550 mm 980 mm 590 mm 74 mm
ROSETTA 3Gr
Tall Cup
550 mm 980 mm 590 mm 124 mm
ROSETTA 3Gr Boilers
550 mm 980 mm 590 mm 74 mm
ROSETTA 3Gr 4 Boil-
ers
Tall Cup
550 mm 980 mm 590 mm 124 mm
