Extech Instruments CG206 User Manual

CG206‐en‐GB_v1.06/16
12
Specifications

 Ferrous Non‐Ferrous
Measurementprinciple Magneticinduction Eddycurrentprinciple
Measuringrange 0~1350μm
0~53.1mils
0~1350μm
0~53.1mils
Accuracy
1

(%ofreading)
0~1000μm:±(2.5%+2μm)
1000μm~1350μm:(±3.5%)
0~39.3mils:±(2%+0.08mils)
39.3mils~53.1mils:(±3.5%)
0~1000μm:±(2.5%+2μm)
1000μm~1350μm:(±3.5%)
0~39.3mils:±(2%+0.08mils)
39.3mils~53.1mils:(±3.5%)
Resolution 0~100μm:(0.1μm)
100μm~1000μm:(1μm)
1000μm~1350μm:(0.01mm)
0~10mils:(0.01mils)
10mils~53.1mil:s(0.1mils)
0~100μm:(0.1μm)
100μm~1000μm:(1μm)
1000μm~1350μm:(0.01mm)
0~10mils:(0.01mils)
10mils~53.1mils:(0.1mils)
Min.curvatureradius 59.06mils(1.5mm) 118.1mils(3mm)
DiameterofMin.area 275.6mils(7mm) 196.9mils(5mm)
Basiccriticalthickness 19.69mils(0.5mm) 11.81mils(0.3mm)
Industrialstandards ConformstoGB/T4956‐1985,GB/T4957‐1985,JB/T8393‐1996,JJG
889‐95,andJJG818‐93
OperatingTemperature 0°C~40°C(32°F~104°F)
OperatingRelative
Humidity(R.H.)
20%~90%RelativeHumidity
Power 2xAAAbatterieswithAutoPowerOFFafter3minutes
Dimensions 120x62x32mm(4.7x2.4x1.25”)
Weight 175g(6.17oz.)
1
Accuracynote:Accuracystatementappliestouseonaflatsurface,withazerocalibration
performedandwiththemeterstabilizedatambienttemperature.Theaccuracyofthereference
filmsoranyreferencestandardssho uldbeaddedtomeasurementresults.


Copyright©2016FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
www.extech.com



