Operation
MeterPower

Installtwo‘AAA’1.5Vbatteriesintotherearbatterycompartment.Pressthepowerbutton
toswitchthemeterON.ThedisplaywillswitchON.IfthedisplaydoesnotswitchON,installor
replacethebatteries.Whenpoweringup,pleasekeepthemeteratleast10cm(4”)frommetal
objects.Replacethebatterieswhenthebatterystatusiconappearslow,themeterwillgive
inaccuratereadingsifthebatteryvoltagefallsverylow.
Measurements

BeforeeachmeasurementsessionpleaseperformaZeroCalibrationasdescribedlaterinthis
UserGuide.

Practicewiththefilmandzeroreferencemetalsubstratestolearnhowthemeteroperates
beforemovingtoaprofessionalapplication.Theheaviermetalsubstrateistheferrous
(magnetic)zerosubstrate(Fe)andthelighter
metalsubstrate(Al)isthenon‐ferrous(non‐
magnetic)zerosubstrate.InAutomode,themeterautomaticallysensesferrousandnon‐ferrous
substrates.

1. Placeareferencefilm(250µm,forexample)ontheferroussubstrate(FE).
2. Powerthemeteronbypressingthepowerbutton.
3. Placethe
spring‐loadedmetersensoragainstthereferencefilm.
4. Themeterwillemitanaudibletoneindicatingthatthemeasurementhasbeentaken.
5. TheLCDwillshowthereadingatthecenterofthedisplayarea.
6. ForatypicaldisplayseetheDisplaydescriptiondiagram.

AutomaticPowerOFF
Inordertoconservebatterylife,themeterwillautomaticallyturnoffafterapproximately3
minutes.Todefeatthisfeature,usetheprogrammingmenudetailedinthenextsection(menu
parameterAUTOPOWEROFFunderSET).

