Extech Instruments EX350 User Manual

EX35x‐en‐GB_V1.212/15
7
DisplayIconDescriptions
 Auto:Automaticrangemode
 HOLD:Displayhold

:Relativemode
 AC:AlternatingCurrentMeasurements
 DC:DirectCurrentMeasurements

:Maindisplaydigits
 A:Amperes(Current)
 V:Volts(Voltage)

o
C/
o
F:Temperatureunits
 F:Farads(Capacitancemeasurementunits)
 Hz:Hertz(Frequencymeasurementsunit)
 %DutyCycle(AConly)
 Ω(Ohms):Resistancemeasurementunit
 LPFVariablefrequencyvoltagemode

:Batterystatusicon
 ‐Minus(negative)sign
 MAX‐MINPeakMaximumandMinimumreadingmemory
 :Diodemeasurementmode

:Continuitymodesymbol

AutoPowerOffenabled
 Prefixes:µ(micro:10
‐6
),m(milli:10
‐3
),n(nano:10
‐9
),k(kilo:10
3
),M(mega:10
6
)

Fig3‐2METERDISPLAY




