Extech Instruments EX655 User Manual

EX65x‐en‐GB_V1.67/16
10
1
2
3
4
5
6
7
8
9
Fig3‐5(a)‐FunctionSwitchDescription(EX655)
1. LowImpedancemodeforACVoltage
measurements
2. MeterPOWEROFFposition
3. AC/DCVoltageandHzforACV(useMODE
buttontochooseAC,Hz,orDC)
4. Frequencymode
5. Capacitance,Continuity,Diode,
Resistancemodes(useMODEbuttonto
choosemode)
6. Temperaturemode
7. 600µAAC/DCCurrent
mode(useMODE
buttontochooseACorDC)
8. AC/DC600ACurrentmode(useMODE
buttontochooseACorDC)
9. Non‐ContactVoltageDetectpositionwith
alertLED

Fig3‐5(b)‐FunctionSwitchDescription(EX650)
1. LowImpedancemodeforACVoltage
measurements
2. MeterPOWEROFFposition
3. AC/DCVoltage(useMODEbuttonto
chooseACorDC)
4. Capacitance,Continuity,Diode,Resistance
modes(useMODEbuttontochoose
mode)
5. 600µAAC/DCCurrentmode(useMODE
buttontochooseACorDC)
6. 6A
ACCurrentmode
7. 60AACCurrentmode
8. 600AACCurrentmode
9. Non‐ContactVoltageDetectpositionwith
alertLED
1
2
3
4
5
6
7
8
9
