Push‐ButtonDescriptions
MomentarypressesoftheM(MODE)buttonperformthefunctionsshowninthe
tablebelow.Pressandholdthebuttontoactivate/deactivatetheLowPassFilter
(EX655only).
Fig.3‐4(a)EX655MODEButtonFunctionTable
SwitchPosition MODE(M)ButtonFunction

ACHzDC
or 
AC DC
Ω

 
TEMP
o
C 
o
F
Fig.3‐4(b)EX650MODEButtonFunctionTable
SwitchPosition MODE(M)ButtonFunction

AC DC
AC DC
Ω

 
Momentarilypresstoaccess/exittheRelativemode.Thismodeofoperationis
onlyavailableforDCvoltage,ACCurrent,Resistance,andCapacitance.
InDCMode,presstozerothedisplay(EX655only)
WhentheEX655isintheACAmode,pressandholdtoaccesstheInrushmode.

PresstoaccesstheMIN/MAXmode.TheMAXiconwillappearalongwiththe
storedhighestreading.Pressagaintoviewtheminimumreadingstored
(MINicon
displayed).Continuetousethebuttoninthismannerasdesired.Pressandhold
thebuttontoexittheMIN/MAXmode.ThismodeofoperationisonlyavailableforAC/DC
Voltage/Current,Resistance,andTemperature.
Pressandholdthisbuttontoactivate/deactivatetheDataHoldfunction.Momentary
pressesswitchthedisplaybacklightONorOFF.
