Extech Instruments PQ2071 User Manual

PQ2071-en-GB_V1.3 7/15
19
Electrical Specifications
Current, Voltage, and Frequency
Active Power (kW)
W = V x A x COSθ
Current / Voltage
Voltage Ranges
100V 400V 750V
Current
Ranges
40A 4.00KW 16.00KW 30.00KW
100A 10.00KW 40.00KW 75.00KW
400A
40.00KW 160.0KW 300.0KW
1000A
100.0KW 400.0KW 750.0KW
Accuracy ±(3%+5)
Resolution <1000KW: 0.01KW; 100kW: 0.1KW
Function
Range &
Resolution
Accuracy (% of
reading + digits)
Overload
Protect
Input
Impedance
Frequency
range
AC Current
40.0 AAC
± (2% + 5d) 1000A N/A 50-60Hz
100.0 AAC
400.0 ADC
1000 ADC
AC Voltage
100.0VAC
± (1.2% + 5d) 750V rms
10M
50-120Hz 400.0 VAC
750.0VAC
Frequency
50 to 200Hz ± (0.5% + 5d)
