PQ2071-en-GB_V1.3 7/15
10
Power Measurements
Active, Reactive, and Apparent Power Measurements
There are three displays modes in this section as detailed in this section:
kW Active Power on Main Display (Phase Angle on Secondary Display)
kVA Apparent Power on Main Display (Reactive power on Secondary Display)
kVAR Reactive Power on Main Display (Apparent power on Secondary Display)
WARNING: To avoid meter damage and personal injury do not measure RMS signals greater
than 750VAC or 1000AAC.
NOTES:
The maximum and minimum values are not available in this mode.
The summing of wattage values is only available in the KW mode.
When the measurement session has been completed, disconnect the test leads from the circuit
under test and remove leads from the meter’s input terminals.
Power connections and measurements shown for
3-Phase 4-wire
3-Phase 3-wire
Single and Split phase
