Automatic Datalogging
In automatic datalogging mode the meter takes and stores a reading at a user-specified sampling
rate onto an SD memory card. The meter defaults to a sampling rate of two seconds. To change the
sampling rate, refer to the Setup Mode section (the sampling rate cannot be ‘0’ for automatic
datalogging):
1. Select the sampling rate in the Setup Mode (refer to Setup Mode section) to a value other than
zero.
2. Press and hold the LOG button for at least 1.5 seconds. The meter will flash the
DATALOGGER icon at the selected sampling rate indicating that readings are now being
automatically recorded to the SD card.
3. If a card is not inserted or if the card is defective, the meter will display SCAN SD indefinitely.
In this case, switch the meter OFF and try again with a valid SD card.
4. Pause the datalogger by pressing the LOG button momentarily. The DATALOGGER icon will
stop flashing. To resume logging simply press the LOG button again momentarily.
5. To terminate the datalogging session press and hold the LOG button for at least 1.5 seconds.
6. When an SD card is used for the first time a folder is created on the card and named SLB01.
Up to 99 spreadsheet documents (each with 30,000 readings) can be stored in this folder.
7. When datalogging begins a new spreadsheet document named SLB01001.xls is created on
the SD card in the SLB01 folder. The data recorded will be placed in the SLB01001.xls
document until 30,000 readings are reached.
8. If the measurement session exceeds 30,000 readings, a new document will be created
(SLB1002.xls) where another 30,000 readings can be stored. This method continues for up to
99 documents, after which another folder is created (SLB02) where another 99 spreadsheet
documents can be stored. This process continues in this same fashion with folders SLB03
through SLB10 (last allowable folder).
SD Data Card to PC Data Transfer
1. Complete a datalogging session as detailed in above in the previous sections. Hint: For the
first few tests, simply record a small amount of test data. This is to ensure that the datalogging
process is well understood before committing to critical, large scale datalogging.
2. With the meter switched OFF, remove the SD Card.
3. Plug the SD Card directly into a PC SD card reader. If the PC does not have an SD card slot,
use an SD card adaptor (available at most outlets where computer accessories are sold).
4. Power the PC and run a spreadsheet software program. Open the saved documents in the
spreadsheet software program (see example spreadsheet data screen below).

Extech Instruments SDL600 Specifications

Display

display size	52 x 38mm (2 x 1.5”) Backlit LCD
display update rate	Approx. 1 second

Microphone

microphone type	12.7mm (0.5”) electret condenser microphone
microphone diameter	12.7mm (0.5”) outer diameter

Measurement

measurement units	Decibels
measurement ranges	30 to 80, 50 to 100, and 80 to 130dB
frequency range	31.5Hz to 8KHz

Power

power supply	Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
power consumption (normal operation)	approx. 12mAdc
power consumption (backlight off, datalogging on)	approx. 51mAdc

Operating Environment

operating temperature	0 to 50°C (32 to 122°F)
operating humidity	85% R.H. max.
auto power off	After 10 minutes of inactivity (can be disabled)

Weight and Dimensions

weight	428g (0.94 lbs.) including batteries
main instrument dimensions	250 x 73 x 47.5mm (9.8 x 2.9 x 1.9”)
