ROOM THERMOSTAT
23
Chapter 7
when the temperature is reached it will take the 2nd motor to 1st speed, making the relative luminous
indicator on the control board  ash.
gure 7.1
casing clamps for additional thermostats connection
Front view right side
Casing clamps for additional thermostat
ducting
Casing clamps for additional thermostat
room
gure 7.2
