Chapter 1
STANDBY: EXPLANATION
With the use of this mode, the stove automatically switches o if the room temperature is higher to that
adjusted by the customer on the display.
The temperature di erence between room and the adjustment made must be higher by 2°C.
Example of automatic switch o :
Room temperature ex.23
Set set by customer ex.20
When the stove is switched o , the room temperature will start to decrease due to the heat loss of the
home.
The moment the room temperature is lower than the adjustment made by the customer on the display,
the stove will automatically re-ignite.
The di erence between the room temperature and that adjusted by the customer must be higher by 2°C.
Example of automatic re-ignition:
Room temperature ex.17
Set set by customer ex.20
STANDBY USE WITH EXTERNAL ADDITIONAL THERMOSTAT
If the customer wants to use an external thermostat the set temperature must be set at minimum from
the display by repeatedly pressing key “2” until LOU appears, alternatively until SET ROOM appears. At
this point, after having connected the external room thermostat to the stove, the room temperature will
be read exclusively by the same thermostat. Therefore, the customer will no longer have to decide the set
temperature from the stove display, but from the external thermostat.
If the STAND-BY mode has been activated the following situation will occur:
External thermostat under request contact closed Stove ignition ON FIRE
Satis ed external thermostat contact open Stove switch-o STBTY EST
