ELISIR CLEANING
43
Chapter 2
CLEANING THE HEAT EXCHANGER (Monthly)4.
The heat exchangers chamber must be cleaned every month as the soot deposited on the rear of the cast
iron hearth wall blocks the regular ow of fumes.
To remove the left side cast iron and clean the exchanger, loosen the screw using the provided Allen
wrench. Once access is gained to the compartment, use the supplied re irons to remove and scrape the
deposited soot. Only afterwards use a speci c vacuum cleaner for the complete removal of the ashes.
When cleaning has been completed, re-position the extractable cast iron with the opposite movement
used to remove it.
gure 2.5 gure 2.6
gure 2.7 gure 2.8
