Chapter 3: Hardware Models for VSP 7200
Series
This section lists the VSP 7200 Series hardware.
Two additional VSP 7200 Series models are available: these are referred to as Port-Licensed
models. By default these models ship with the first twenty-four of the forty-eight 10 Gigabit ports
(SFP+ or RJ45), and the first four of the six 40 Gigabit ports, enabled. The remaining twenty-four 10
Gigabit ports and the remaining two 40 Gigabit ports can be field-enabled through the purchase and
installation of the optional Port License.
VSP 7200 Series hardware
Note:
Power cords must be ordered separately. Ensure you order the correct power cord for your
region. For more information, see
Power cord types and order codes on page 14.
Table 3: VSP 7200 Series Hardware
VSP 7200 Series
Description Part numbers
VSP 7200 Series AC models
VSP 7254XSQ – fiber switch
Model EC7200x1B-E6 ships
with back-to-front fan modules
and one back-to-front 460 W
AC PSU.
Model EC7200x1F-E6 ships with
front-to-back fan modules and
one front-to-back 460 W AC
PSU.
• 48 1/10 GbE SFP/SFP+ ports
• six 40 GbE QSFP+ ports
• one 10/100/1000 BASE-T Out-Of-Band
Management Port
• one RJ-45 Console Port
• one USB 2.0 port
• Base Software License
• three field-replaceable fan modules
EC7200A1B-E6 and
EC7200A1F-E6
VSP 7254XSQ – Port-Licensed
fiber switch
Includes all of the above components, with
the following changes:
• 24 ports (Slot 1, ports 25 to 48) out of the
48 1/10 GbE SFP/SFP+ ports require a port
license to be operational.
EC7200A3B-E6 and
EC7200a3F-E6
Table continues…
March 2020 Installing the VSP 7200 Series 10
