Extron electronics CrossPoint 450 Plus Series Setup Guide

16 CrossPoint / MAV Matrix Switchers • Remote Control
Command SIS command
(host to switcher)
Response (switcher to host)
Aditional information
Create and view ties
NOTES:
• Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*24$. • The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%). • The & tie command for RGB and the % tie command for video can be used interchangeably. • The & read tie command for RGB and the % read tie command for video can be used interchangeably.
Tie input
to output
X@
, video and audio
X!
*
X@
! Out
X@•
In
X!•
All] Tie input
X!
video and audio to output
X@
.
Example:
1*3!
Out03
•
In01
•
All
]
Tie input 1 video and audio to output 3.
Tie input
X!
to output
X@
,
RGBHV only
X!
*
X@
& Out
X@•
In
X!•
RGB
]
Audio breakaway.
Example (see 3rd NOTE bullet, above):
10*4&
Out04
•
In10
•
RGB
]
Tie input 10 RGB to output 4.
Tie input
X!
to output
X@
, video only
X!
*
X@
% Out
X@•
In
X!•
Vid
]
Audio breakaway.
Example (see 3rd NOTE bullet, above):
7*5%
Out05
•
In07
•
Vid
]
Tie input 7 video to output 5.
Tie input
X!
to output
X@
, audio only
X!
*
X@
$ Out
X@•
In
X!•
Aud
]
Audio breakaway.
Example:
24*04$
Out04
•
In24
•
Aud
]
Tie input 24 audio to output 4.
Read RGB output tie
X@
&
X!]
RGBHV input
X!
is tied to output
X@
.
Read video output tie
X@
%
X!]
Video input
X!
is tied to output
X@
.
Read audio output tie
X@
$
X!]
Audio input
X!
is tied to output
X@
.
KEY: X! = Input number
00
– (maximum number of inputs for your model) (00 = untied)
X@ = Output number
01
– (maximum number of outputs for your model)
