Extron electronics CrossPoint 450 Plus Series Setup Guide

18 CrossPoint / MAV Matrix Switchers • Remote Control
Command SIS command
(host to switcher)
Response (switcher to host)
Aditional information
Audio output volume
Set the audio volume to a specic value
X@
*
X%
V Out
X@
•Vol
X%]
Example:
1*50v
Out01•Vol50
]
Set output 1 volume to a value of 50 (79% of max volume, 14 dB of attenuation).
Increment volume
X@
+V Out
X@
•Vol
X%]
Increase volume by 1 step.
Example:
1+V
Out01•Vol51
]
Decrement volume
X@
-V Out
X@
•Vol
X%]
Decrease volume by 1 step.
Read output volume
X@
V
X%]
Save and recall presets
NOTES:
• If you try to recall a preset that is not saved, the matrix switcher responds with the error code E11. • The following characters are invalid in preset names: + - , ` @ = [ ] { } ‘ “ ; : | \ and ?.
Save current conguration as a global preset
X^
, Spr
X^]
Command character is a comma.
Example:
9
,
Spr09
]
Save current ties as preset 9.
Recall a global preset
X^
. Rpr
X^]
Command character is a period.
Example:
5
.
Rpr05
]
Recall preset 5, which becomes the current conguration.
KEY: X@ = Output number
01
– (maximum number of outputs for your model)
X% = Volume
0
–
64
(1 dB/step except for 0-to-1, which is 22 dB) (default =
64
[0 dB])
X^ = Preset number
00
–
32
(
00
= current conguration)
