PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS
©2011-2023 Eyedro Green Solutions Inc. Page | 11
COMMON CIRCUIT TYPES
The most common application of Eyedro Electricity Monitoring products is for monitoring of the electrical
service entrance of a building. However, there are other common applications where Eyedro Electricity
Monitoring products are often used. The following sub-sections provide a brief overview of some of the
common and less common applications.
To use Eyedro Electricity Monitoring products in one of these applications, follow ALL instructions and
precautions from the current sensor installation procedure
but substitute step 4 to install the sensors on
the line conductor of your desired circuit.
3-PHASE WYE MONITORING
