Eyedro E5B-EW-E3 - Connecting Cabling and Power; Materials and Tools for Cabling; Ethernet Installation Procedure

PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS
©2011-2023 Eyedro Green Solutions Inc. Page | 20
CONNECT CABLING
MATERIALS YOU WILL NEED
• Ethernet cable
• Low-voltage power adapter(s)
• Tie wraps (optional – not included)
TOOLS YOU WILL NEED
• None
IMPORTANT
Ensure all connectors and sockets are free from damage prior to mating them.
If applicable, ensure the retention clip on the Ethernet cable is intact.
Never force connectors or apply levering action.
Ensure all connections are secure.
For devices with both Ethernet and Wi-Fi (ExB.ENWI.*E), the Ethernet cable must be plugged
in before power is applied to the device for Ethernet communication to be used.
PROCEDURE (ETHERNET INSTALLATIONS)
1. Connect sensor cables to the Eyedro module.
2. Connect one end of Ethernet cable to Eyedro module.
3. Connect the other end of the Ethernet cable to the router (or Internet access point).
4. Connect the appropriate end of the low-voltage power adapter to the Eyedro module.
Electricity monitoring devices (with sensors) use a power supply with a 6V AC output.
5. Plug the other end of the low-voltage power adapter into a nearby AC wall receptacle.
Devices should not be plugged into a UPS (Uninterruptible Power Supply) as they may
result in inaccurate/incorrect measurements.
Electricity monitoring devices (with sensors) must be powered by a receptacle that is
downstream of the panel where the current sensors are installed.
6. Secure all wiring neatly with tie wraps.
