PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS
©2011-2023 Eyedro Green Solutions Inc. Page | 26
SPECIFICATIONS
HARDWARE SPECIFICATIONS
Ethernet + Wi-Fi
Mesh
1
Power Supply
Class 2 Power Supply
Input: 120Vac, 60Hz (North America/Type A)
Input: 240Vac, 50Hz (Europe/Type C)
Output: 6Vac, 0-350mA
Ambient Operating
Conditions
0°C to 50°C
(32°F to 122°F)
80% relative humidity
Storage Conditions
-20°C to 70°C
(-4°F to 158°F)
80% relative humidity
Module Dimensions
(W x H x D)
77 x 75 x 25 mm
(3 x 3 x 1 in)
Parts Included
1x EMx.ENWI.*E
1-3x Current Sensors
1x 10ft Ethernet Cable
1x 6V AC Power Adapter
1x EMx.NODE.*E
1-3x Current Sensors
1x 6V AC Power Adapter
1x EMx.GATE0N*
1
1x 3ft Ethernet Cable
1
1x 5V DC Power Adapter
1
Weight
[approximate]
2
0.800 kg
(1.8 lbs)
0.953 kg
(2.1 lbs)
Wireless Link
IEEE 802.11 b/g/n
2.412 to 2.484 GHz
IEEE 802.15.4
2.405 to 2.480 GHz
Wireless Range
[typical]
3
Indoors: 50m (150ft)
Line of sight: 100m (300ft)
Indoors: 150m (500ft)
Line of sight: 300m (1000ft)
1
Gateway, (1) Power Supply and Ethernet cable are not included in Wireless Expansion products (ExB-M-*E)
2
Approximate weight is based on standard two (2) sensor models including packaging and contents. Mesh assumes complete
system (gateway and node).
3
Wireless range is dependent on the location and environment that device(s) are installed in. Typical values provided.
SENSOR SPECIFICATIONS
Sensor Input Output Accuracy Core Opening
Cable
Length
200A
(ESCLV-25-200A)
0 to 200Aac
600V 50/60Hz
0 to
0.333Vac
±1%
Typical
1
Ferrite
19.00 mm
(0.75 in)
2000 mm
(79 in)
1
Accuracy noted is for sensor readings at 10% to 90% of rated current. This product also requires a continuous internet connection.
