Page 61 of 72
7.4. LANDING PAD
7.4.1. The PLP (LANDING PAD) is used at the bottom of a ramp or ramp run to assist mobility on
soft ground. Contour the ground to remove any high or low areas which would prevent
portions of the Landing Pad from contacting the ground.
WARNING The Landing Pad is intended for use on the ground only. The underside of
the Landing Pad must be fully supported by the ground. It should never be used in
an elevated position like a ramp or a platform.
7.4.2. Slide the bottom plate into one of the three available slots (FIG. 7.5).
The ramp must be installed on the side marked for ramp attachment.
7.4.3. After installing the bottom plate, install #8-32 hex washer head thread cutting screws
into the screw slots on both sides (FIG. 7.6).
FIG. 7.5
FIG. 7.6
