EZ-ACCESS PATHWAY 3G - Section 2: Platforms

Page 8 of 72
PLATFORMS AND PLATFORM HANDRAIL OPTIONS
PLATFORM (STRAIGHT CONFIGURATION) PLATFORM (TURN CONFIGURATION)
PLATFORM (8’ X 5’ TURN BACK) PLATFORM* WITH SINGLE-LINE HANDRAIL
PLATFORM* WITH VERTICAL PICKET HANDRAIL PLATFORM* WITH HORIZONTAL PICKET HANDRAIL
*RAMP OR PLATFORM NOT INCLUDED
